This work focuses on the analysis and design of microstrip patch antennas (MPA) and enhancement of properties like gain, directivity and return loss using metamaterial superstrate. Microstrip antennas are preferred because of their compatibility to fit in aircrafts, mobiles, and satellites because of the small sizes. So, it is the need of the hour to develop effective and superior microstrip patch antenna.In this report, we present the design of rectangular microstrip patch antenna incorporated with innovative metamaterial structure for dual band operation at 2.478 GHz and 2.919 GHz.
Cst Studio Suite Pdf
Simulations are performed using CST Studio Suite. The simulation results confirm that when incorporated with metamaterial structure the patch antenna achieves better return loss.Also, in this work, the gain of the patch antenna operating at 2.55 GHz is improved when the metamaterial composed of ring aperture lattice (9 x 9) was placed at a distance'd' from the ground plane.
Cst Studio Suite 2018 Price
The improvement in gain and directivity is also marked. The designed structures are characterized using CST Studio Suite at variable frequencies, dielectrics and substrate thicknesses.
